A) For Regular Users

---

• Calculate your load (W): Convert to VA → VA ≈ W ÷ Power Factor (pf)
  (if unknown, assume pf = 0.7–0.8).


• Add a safety margin: Always choose a UPS with 20–30% more
  capacity than your total load.


• Decide on runtime: How long do you need backup?
  (e.g., 10–15 mins to shut down safely).


• Pick the right topology: Line-Interactive for home/office use;
  Online for highly sensitive equipment.


Example

PC (300W) + Monitor (60W) + Router (20W) = 380W.

With pf=0.8 → 475 VA.

Add 30% margin → ~650 VA.

So, choose a 700–1000 VA UPS for comfort.

B) For Engineers & IT Managers

---

• Topology:


• Normal office with moderate fluctuations → Line-Interactive.


• Mission-critical or zero-downtime environments → Online
  (Double Conversion).



• Key Specs to Check:


• Capacity (kVA) with Power Factor (0.9 recommended).


• Low Total Harmonic Distortion (THD) output.


• Crest factor for devices with high inrush currents.


• Scalability (modular, N+1 redundancy).


• Monitoring & control (USB/SNMP).


• Battery type (VRLA vs. Li-ion), lifespan, and temperature ratings.


• Compliance with medical/industrial standards.

C) Common Mistakes to Avoid

---

• Buying a UPS too close to your actual load (no margin).


• Ignoring required runtime.


• Forgetting startup/inrush currents of some devices.


• Overlooking environmental conditions (heat, dust, ventilation).
