Schneider Electric Circuit Breaker ComPact NSX100B, 25 kA at 415 VAC, MicroLogic 2.2 Trip Unit 100 A, 3 Poles 3d
This Compact NSX100B is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 25kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds an electronic Micrologic 2.2 trip unit, with 100A rating. Micrologic 2.2 trip unit provides adjustable long time and short time protections, and a fixed instantaneous protection. This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. Compact NSX100B is part of Schneider Electric EcoStruxure Power architecture.
We accept: See all payment methods
Terms and Conditions
In line with our shipping guidelines, the vast majority of products in our store typically require 24 business hours for order processing and preparation prior to shipment.
Certain items with unique characteristics may require specific storage or production protocols, making them temporarily unavailable at the time of fulfillment or requiring additional production time.
Fast Shipping | Easy Returns | Best Price Guarantee |
Documents
Internal Reference:
LV429775
Specifications
| Brand | Schneider Electric |
| Product Range | ComPacT NSX |
| Poles | 3P |
| Rated Current | 100 A |
| Breaking Capacity | 25 kA |
